Home I/O Devices & Communication Industrial Communication Ethernet Switches Unmanaged Switches

Unmanaged Switches

Advantech’s Unmanaged Industrial Ethernet Switches are truly plug-and-play. These Industrial Ethernet Switches are designed for use in demanding industrial environments, offering unmatched performance, reliability, and value. We strengthen our Unmanaged Ethernet Switch products with power polarity reverse protection and overload current resettable fuse functions to bring you both a quick and stable connection experience.
category
  1. Industrial Communication (242)
  2. Programmable Controllers (PACS) (31)
  3. Remote I/O Modules (75)
  4. USB IO Modules (31)
  5. Wireless IoT Sensors (13)
Results per page 2040 | Sort by Price Highest / Lowest / Latest
Page 1 of 1
Compare(0)
5 FE Unmanaged Industrial Ethernet Switch with Wide Temperature Low VAC Power Input
BB-ESW105-A
5 FE Unmanaged Industrial Ethernet Switch with Wide Temperature Low VAC Power Input
  1. 5 x fast Ethernet ports with auto MDI/MDI-X
  2. Supports 10/100 Mbps auto negotiation
  3. Compact size with DIN rail and wall mount
  4. IP40-rated metal enclosure
  5. Supports redundant 12~48 VDC or 10~24 VAC power input
  6. Wide operating temperature range of -40 ~ 75°C
  7. C1D2 for hazardous locations

$138.26

Compare View More
8 FE Unmanaged Industrial Ethernet Switch with Wide Temperature Low VAC Power Input
BB-ESW108-A
8 FE Unmanaged Industrial Ethernet Switch with Wide Temperature Low VAC Power Input
  1. 8 x fast Ethernet ports with auto MDI/MDI-X
  2. Supports 10/100 Mbps auto negotiation
  3. Compact size with DIN rail and wall mount
  4. Supports redundant 12~48 VDC or 10~24 VAC power input
  5. Wide operating temperature range of -40 ~ 75°C
  6. C1D2 for hazardous locations

$217.80

Compare View More
8-port Unmanaged Switch with DNV Compliant
EKI-2528DI-AE
8-port Unmanaged Switch with DNV Compliant
  1. Provides 8-port Fast Ethernet ports with Auto MDI/MDI-X
  2. Supports 10/100 Mbps Auto-Negotiation
  3. Provides broadcast storm protection
  4. Provides compact size with DIN-rail/Wall mount, and IP30 metal mechanism
  5. Supports redundant 12 ~ 48 VDC power input and P-Fail relay
  6. EKI-2528DI supports wide operating temperatures from -40 to 75°C
  7. DNV certificate

$157.85

Compare View More
8-port Industrial Unmanaged GbE Switch W/T
EKI-2728I-CE
8-port Industrial Unmanaged GbE Switch W/T
  1. Provides 8 Gigabit Ethernet ports with Auto MDI/MDI-X
  2. Supports 10/100/1000Mbps Auto Negotiation
  3. Supports jumbo frame transmission up to 9kbytes
  4. Provides Slim size, DIN-rail with IP30 metal mechanism
  5. Supports Redundant 12 ~ 48 VDC power input and P-Fail Relay
  6. Provides broadcast storm protection
  7. Supports a wide temperature range: -40 ~ 75° C

$369.94

Compare View More
5-port Wide Operating Temp. Industrial Switch
ADAM-6520I-AE
5-port Wide Operating Temp. Industrial Switch
  1. Supports full/half duplex flow control
  2. Supports MDI/MDI-X auto crossover
  3. Provides broadcast storm protection
  4. Embedded with a switch controller, supports auto-negotiation
  5. Supports 10~30 VDC for power input
  6. Provides surge protection 3,000 VDC for power line
  7. Supports 4,000 VDC Ethernet ESD protection
  8. Provides flexible mounting: DIN-rail, Wall, Stack
  9. Supports wide operating temperature range: -40 ~ 85� C

$195.00

Compare View More
5-port 10/100 Mbps Unmanaged Switch
ADAM-6520L-AE
5-port 10/100 Mbps Unmanaged Switch
  1. Supports full/half duplex flow control
  2. Supports MDI/MDI-X auto crossover
  3. Provides broadcast storm protection
  4. Embedded with a switch controller, supports auto-negotiation
  5. Supports 10~30 VDC for power input
  6. Provides surge protection 3,000 VDC for power line
  7. Provides flexible mounting: DIN-rail, Wall, Stack

$108.90

Compare View More
5-port Switch w/1 M-Mode ST Type Fiber Port
ADAM-6521/ST-AE
5-port Switch w/1 M-Mode ST Type Fiber Port
  1. Provides 4 x 10/100 Mbps Ethernet ports with RJ-45 connector
  2. Provides 1 x 100 Mbps multi/single-mode fiber port with ST connector
  3. Supports full/half duplex flow control and Integrated Loop-up engine
  4. Supports MDI/MDI-X auto crossover and loop detection
  5. Supports 10 ~ 30 VDC voltage power input
  6. Provides surge protection (EFT) 3,000 VDC for power line
  7. Supports 4,000 VDC Ethernet ESD protection
  8. Provides flexible mounting: DIN-rail, panel, piggyback
  9. Supports operating temperatures from -10 ~ 65°C

$231.27

Compare View More
5-port Switch w/1 Multi-Mode Fiber-Optic Port
ADAM-6521-BE
5-port Switch w/1 Multi-Mode Fiber-Optic Port
  1. Provides 4 x 10/100 Mbps Ethernet ports with RJ-45 connector
  2. Provides 1 x 100 Mbps multi/single-mode fiber port with SC/ST connector
  3. Supports full/half duplex flow control
  4. Supports Integrated Loop-up engine
  5. Supports MDI/MDI-X auto crossover
  6. Provides broadcast storm protection
  7. Supports 10 ~ 30 VDC voltage power input
  8. Provides surge (EFT) protection 3,000 VDC for power line
  9. Supports 4,000 VDC Ethernet ESD protection
  10. Provides flexible mounting: DIN-rail, Wall, Stack
  11. Supports operating temperatures from -10 ~ 65� C

$231.27

Compare View More
5-port Switch w/1 Single-Mode Fiber-Optic Port
ADAM-6521S-AE
5-port Switch w/1 Single-Mode Fiber-Optic Port
  1. Provides 4 x 10/100 Mbps Ethernet ports with RJ-45 connector
  2. Provides 1 x 100 Mbps multi/single-mode fiber port with SC connector
  3. Supports full/half duplex flow control
  4. Supports MDI/MDI-X auto crossover
  5. Provides broadcast storm protection
  6. Embedded with a switch controller, supports auto-negotiation
  7. Embedded with the memory buffer, supports store-and-forward transmission
  8. Support 10 ~ 30 VDC voltage
  9. Provides surge protection 3000 VDC for power line
  10. Provides flexible mountings: DIN-rail, panel, piggyback
  11. Supports operating temperature: -10 ~ 65�C

$370.65

Compare View More
Ethernet to M-Mode ST Type Fiber-optic Converter
ADAM-6541/ST-AE
Ethernet to M-Mode ST Type Fiber-optic Converter
  1. Supports full/half duplex flow control
  2. Supports Integrated Loop-up engine
  3. Supports MDI/MDI-X auto crossover
  4. Provides broadcast storm protection
  5. Supports +10 ~ 30 VDC voltage power input
  6. Provides surge protection (EFT) 3,000 VDC for power line
  7. Provides flexible mounting: DIN-rail, panel, piggyback
  8. Supports operating temperatures from -10 ~ 65° C
  9. Embedded a switch controller-supports auto-negotiation
  10. Embedded a memory buffer-supports store and forward transmission

$209.98

Compare View More
Ethernet to Multi-Mode Fiber-Optic Converter
ADAM-6541-AE
Ethernet to Multi-Mode Fiber-Optic Converter
  1. Supports 1-port 100 Mbps multimode fi ber optics
  2. Supports 10 ~30 VDC power input
  3. Easily mounted on a DIN-rail, panel or piggyback
  4. Supports full/half-duplex fl ow control.
  5. Supports MDI/MDIX auto crossover.
  6. Embedded with a switch controller, supports auto-negotiation.
  7. Embedded with memory buffer, supports store and forward transmission.
  8. Multi-mode
  9. 13.10nm Wavelength

$209.98

Compare View More
Compare(0)
Page 1 of 1
