Results per page 2040 | Sort by Price Highest / Lowest / Latest
Page 1 of 9
ADAM-4015-CE
6-channel RTD Module with Modbus
  1. 6-channel 2 or 3 wires RTD Input
  2. Accept Pt100/1000, Balco500, Ni input signals
  3. Channels configurable for different types of input individually
  4. Wiring burned-out detectable function
  5. 3000 VDC A/D to logic isolation

$412.00

Compare View More
ADAM-4017+-CE
8-Channel Analog Input Module with Modbus®
  1. 16-bit resolution
  2. Eight different inputs
  3. Software configurable for mV, V or mA inputs
  4. 3000 Vdc isolation
  5. Supports Modbus/RTU Protocol
  6. Supports 4~20mA

$324.00

Compare View More
ADAM-4018+-BE
8-Channel Thermocouple Input Module with Modbus®
  1. 16-bit resolution
  2. Eight different inputs
  3. Software configurable for T/C, low level voltage or mA inputs
  4. Wiring burned-out detectable function
  5. 3000 Vdc isolation
  6. Supports Modbus/RTU Protocol
  7. Supports 4~20mA

$341.00

Compare View More
ADAM-4019+-AE
8-Channel Universal Analog Input Module with Modbus®
  1. Supports 4~20 mA
  2. Software configurable for mV, V, mA or Thermocouple inputs
  3. 16-bit resolution
  4. Isolation voltage 3000 VDC
  5. Supports Modbus/RTU Protocol
  6. Burn-out detection function
  7. 8-channel Universal Analog Input

$418.00

Compare View More
ADAM-4024-B1E
4-Channel Analog Output Module with Modbus®
  1. 12-bit resolution
  2. Software configurable for mA or V output in individual channels
  3. 4 digital inputs for latch output
  4. 3000 VDC D/A to Logic isolation
  5. Programmable output slope: 0.125 - 128.0 mA/sec. 0.0625 - 64 V/sec.

$329.00

Compare View More
ADAM-4051-BE
16-Channel Isolated Digtal Input Module with LED & Modbus®
  1. 16 digital input channels
  2. Digital input for dry contact or wet contact
  3. Input Voltage level: 10~50V
  4. Over voltage protection: 70 Vdc
  5. 2,500 Vdc optical isolation

$170.00

Compare View More
ADAM-4055-BE
16-Channel Isolated Digtal I/O Module with LED & Modbus®
  1. I/O type: 8 DO/DI
  2. Input Voltage level: 10~50 VDC
  3. Open Collector to 40 VDC
  4. Over voltage protection: 70 VDC
  5. 2,500 VDC optical isolation

$170.00

Compare View More
ADAM-4056S-AE
12-Channel Sink Type Isolated Digtal Output Module with Modbus®
  1. Sink Type: Digital Output
  2. Digital Output: Open collector to 40V (200 mA max. load)
  3. 12 Channels
  4. I/O Type: Sink Type Output

$157.00

Compare View More
ADAM-4056SO-AE
12-Channel Source Type Isolated Digtal Output Module with Modbus®
  1. DO Source Power Failure Detection
  2. I/O Type: Source Type Output
  3. 12 Channels
  4. Digital Output: VCC: 1-~35 Vdc, Current: 1A (per ch.)
  5. Over Current Detection

$186.00

Compare View More
ADAM-4068-BE
8-Channel Relay Output Module with Modbus®
  1. I/O type: 8 channels from C (NO/NC selectable)
  2. Contact rating: AC: 125 V @ 0.6 A; 250 V @ 0.3 A, DC: 30 V @ 2 A; 110 V @ 0.6 A
  3. Switch Time: Relay on time (typical): 3 msec, relay off time (typical): 1 msec.
  4. LED Indicators
  5. Supports Modbus/RTU protocol

$198.00

Compare View More
ADAM-4510I-AE
Robust Wide-Temperature RS-422/485 Repeater
  1. Wide Operating Temperature: -40 ~ 85° C
  2. Automatic RS-485 data flow control
  3. 3000 VDC isolation protection
  4. Surge protection RS-485 data line
  5. Transmission speed up to 115.2 Kbps
  6. Networking up to 1200 meters (4000 feet)
  7. Reserved space for termination resistors
  8. Power requirement: +10 to +30 VDC w/power reversal protection
  9. Mounts easily on a DIN-rail, panel or piggyback

$217.00

Compare View More
ADAM-4520I-AE
Robust Wide-Temperature RS-232 to RS-422/485 Converter
  1. Wide Operating Temperature: -40 ~ 85° C
  2. Automatic RS-485 data flow control
  3. 3000 VDC isolation protection
  4. Surge protection RS-485 data line
  5. Transmission speed up to 115.2 Kbps
  6. Networking up to 1200 meters (4000 feet)
  7. Engineer features incl. reserved space for termination resistors, power and data flow indicators
  8. Power requirement: +10 to +48 VDC
  9. Mounts easily on a DIN-rail, panel or piggyback

$157.00

Compare View More
ADAM-6022-A1E
Ethernet-based Dual-loop PID Controller
  1. 2 loop PID control algorithms built in one package
  2. 3 analog input/1 analog output/1 digital input/1 digital alarm output for 1 PID loop
  3. Support multiple analog I/O ranges: 0 ~ 10 VDC, 0 ~ 20 mA and 4 ~ 20 mA
  4. Support heating/cooling (direct/reverse) action mode
  5. Support loop open/close (PID disable/enable) and analog output manual control modes
  6. Built-in watchdog timer

$514.00

Compare View More
ADAM-6024-A1E
12-Channel Isolated Universal I/O Modbus® TCP Module
  1. 6 differential channels
  2. 16-bit effective resolution
  3. Isolation Voltage: 2,000 VDC
  4. Sampling Rate: 10 samples/sec.

$534.00

Compare View More
TPC-1881WPH-9S51
18.5 FHD TFT LED LCD Intel® 4th Generation Core i5 Multi-Touch Panel Computer
  1. Industrial 18.5 FHD TFT LCD with 50K Lifetime LED Backlight
  2. Intel 4th Generation Core i5 4300U with 4GB/8GB DDR3L SDRAM
  3. Certified with UL CID2 for hazardous environments
  4. IP66 Approved Front Protection & Panel Mounting
  5. Diverse system IO and Isolated Digital IO by iDoor Technology
  6. Supports Fieldbus Protocol by iDoor Technology
  7. Supports Battery-backup MRAM by iDoor Technology

$3,205.00

Compare View More
TPC-125H-1
12" XGA TFT LED LCD Thin-Client Terminal with Intel® Atom™ Processor and UL Class 1, Division 2
  1. Features a 12" XGA TFT LED LCD screen
  2. Built with Intel® Atom E3845 1.91GHz Quad core processor
  3. 4GB Memory and 64GB SSD Built-in
  4. UL C1D2 certified HMI for Hazardous environment
  5. Hazardous Location Designation Group A, B, C, D, T4
  6. -20 ~ 60° C wide operating temperature
  7. Compact, fanless design with aluminum alloy front bezel
  8. True-flat with IP66 certified front panel protection

$1,455.00

Compare View More
IGNE-TPC1881WPH-1
Class I, Division 2 Certified, TPC-1881WPH, 18.5" Multi-touch Panel Computer, Intel® Core™ i5, Ignition Edge(Windows)
  1. Industrial 18.5 FHD TFT LCD with 50K Lifetime LED Backlight
  2. Intel 4th Generation Core i5 4300U
  3. 4GB DDR3L Memory Built In
  4. Certified with UL CID2 for hazardous environments
  5. IP66 Approved Front Protection & Panel Mounting
  6. Diverse system IO using iDoor technology
  7. Ignition Edge Software

$3,795.00

Compare View More
FPM-8151H-R3BE
15" XGA Ind. Monitor VGA/DVI, -20-60C, C1D2
  1. 15" XGA TFT LCD with LED backlight
  2. Stainless steel 316L front panel
  3. IP65 compliant front panel
  4. -20 ~ 60°C (-4 ~ 140°F) wide operating temperature range
  5. Enhanced 5-wire resistive touch panel
  6. Direct VGA & DVI-D video input interface
  7. Combo RS-232 & USB interface for touchscreen function
  8. Supports 24 VDC input and 100~240 VAC input (optional AC adapter)
  9. OSD control pad with lockable function on front panel

$1,760.00

Compare View More
UNO-1372GH-3S53
Class I, Division 2 Certified Intel® Atom™ Quad-Core Control DIN-rail PC
  1. UL listed for Hazardous Locations: Class I, Division 2
  2. Intel® Atom E3845 1.91GHz processor with 4GB DDR3L Memory
  3. 3 x GbE, 3 x USB, 2 x COM, 1 x VGA, 1 x HDMI, Audio, iDoor, mSATA, 2 x mPCIe, 1 x SATA, 4 x DI, 4 x DO, 1 x Power Terminal
  4. Dual Power Input for Avoiding Power Down Time; Exchangeable RTC Battery with easy Access on the Top
  5. Digital I/O with Isolation Protection for Sensing and controlling; Diverse system IO and Supports Fieldbus Protocol by iDoor Technology as a Protocol Gateway
  6. 3G/GPS/GPRS/WiFi Communication by iDoor Technology as a Communication Gateway; Supports MRAM by iDoor Technology; LAN Redundancy (Teaming)

$1,360.00

Compare View More
IGNE-UNO1372GH-1
Class I, Division 2 Certified, UNO-1372GH, Intel® Atom™ Quad-core E3845 Din-rail Edge Gateway, Ignition Edge(Linux)
  1. UL listed for Hazardous Locations: Class I, Division 2
  2. Intel® Atom E3845 1.91GHz processor with 4GB DDR3L Memory
  3. 3 x GbE, 3 x USB, 2 x COM, 1 x VGA, 1 x HDMI, Audio, iDoor, mSATA, 2 x mPCIe, 1 x SATA, 4 x DI, 4 x DO, 1 x power terminal
  4. Dual Power Input for Avoiding Power Down Time; Exchangeable RTC Battery with easy access on the top
  5. Diverse system IO by iDoor technology
  6. Ignition Edge Software

$1,885.00

Compare View More
Page 1 of 9
