TPC-121W-1 21.5" Touch Panel Computer with ARM Cortex™-A53 Processor

TPC-121W-N32YB
  • TPC-121W-N32YB
  • TPC-121W-N32YB
  • TPC-121W-N32YB
  • TPC-121W-N32YB
  • TPC-121W-N32YB
  • TPC-121W-N32YB
  • TPC-121W-N32YB

  1. NXP® ARM® Cortex™-A53 i.MX 8M Mini Quad Core Processor
  2. 21.5" 16:9 LCD with multi-touch P-CAP and true-flat IP66-rated front panel
  3. 4GB DDR4 RAM and 16GB eMMC storage onboard
  4. 2 x 10/100/1000 Mbps LANs
  5. 1 mb FRAM backup memory for unexpected power interruptions
  6. 2 x Serial port with 120Ω termination resistor that one supports the CAN 2.0B protocol and offers a programmable bit rate of up to 1 Mb/sec
  7. Embedded browser and for rapid Web App development
  8. Supports Linux Yocto 4.2 and Android 13
Certifications
CE CE CE CE CE CE
Resources
  • Base System
Please visit via PC to place order/quote

$1,460.00

2 years extended warranty
Request Quantity Discount Preview Add to Quote Add to Cart
Configure System
  • Configure Your System
  • Accessories
Base System
Base System : 21.5" Touch Panel Computer, Cortex™-A53 Quad Core CPU, 4GB DDR4, 16G eMMC, w/CAN, Yocto
21.5" Touch Panel Computer, Cortex™-A53 Quad Core CPU, 4GB DDR4, 16G eMMC, w/CAN, Yocto
[ +$0.00 ]
Storage Device : 16GB eMMC Storage Onboard
16GB eMMC Storage Onboard
[ +$0.00 ]
Wireless LAN Connectivity
Wireless LAN Connectivity : None
None
[ +$0.00 ]
M.2 2230 WiFi Kit for TPC-100W
[ +$49.29 ]
Operating System
Operating System : Includes Linux Yocto 4.2 or Android 13
Includes Linux Yocto 4.2 or Android 13
Power Adapter
Power Adapter : None
None
[ +$0.00 ]
ADP A/D 100-240V 60W 24V
[ +$49.64 ]
Assembly and Testing
Assembly and Testing : Standard Assembly, Functional Testing, w/o SW installation
Standard Assembly, Functional Testing, w/o SW installation
[ +$0.00 ]
Extended warranty
Extended warranty : NoneExtended Warranty Details
None
[ +$0.00 ]
Extended Warranty for 3 Months
[ +$14.24 ]
Extended Warranty for 6 Months
[ +$28.48 ]
Extended Warranty for 12 Months
[ +$56.96 ]
Extended Warranty for 24 Months
[ +$128.16 ]
Extended Warranty for 36 Months
[ +$213.60 ]
Keyboard + Mouse
Keyboard + Mouse : None
None
[ +$0.00 ]
Logitech MK120 KB + Mouse USB US
[ +$30.14 ]

Comment

Specifications
Category
Attribute
Value
System
System
21.5" Touch Panel Computer with Cortex™-A53 Quad Core CPU
Processor
Processor
NXP® ARM® Cortex™-A53 i.MX 8M Mini Quad Core 1.6 GHz Processor
Memory
Memory
4GB DDR4 Memory Built-in
Storage
Storage
16GB eMMC Onboard
Expansion Slots
Expansion Slots
1 x Micro-SD Slot
Display Size
Display Size
21.5"
Display Type
Display Type
FHD TFT LCD
Max. Resolution
Max. Resolution
1920 x 1080
Max. Colors
Max. Colors
16.7M
Luminance
Luminance
250 nits
Touchscreen
Touchscreen
Projected Capacitive
I/O Ports
I/O Ports
1 x RS-232/422/485 (COM 1)
1 x selectable mode for RS-485 and CAN 2.0B (COM 2)
2 x RJ45 (10/100/1000 Mbps)
2 x USB 2.0 Type-A Host
1 x USB 2.0 Type-B Client (Internal)
Power Input Voltage
Power Input Voltage
24 VDC +/- 20%
Power Consumption
Power Consumption
Typical: 9W
Max: 21W
Operating System
Operating System
Linux Yocto 4.2
Android 13
Operating Temperature
Operating Temperature
-20 ~ 60° C (-4 ~ 140° F)
Dimensions (W x H x D)
Dimensions (W x H x D)
558.4 x 349.8 x 52 mm ( 22 x 13.8 x 2.05 in.)
Mounting Options
Mounting Options
Panel Mount
VESA Mount
Certification
Certification
BSMI, CCC, CE, FCC Class A, UL
