Memory
Socket
1 x 262-pin SO-DIMM
Memory
Technology
DDR5 up to 4800MHz
Processor
BIOS
AMI EFI 256 Mbit
Processor
CPU
Intel Atom® x7211E
Processor
Frequency
1.0GHz, Max Turbo Frequency up to 3.2GHz
Storage
SATA and PCIe/NVMe
3x, including 1x M.2 2230 E key (PCIe x1), 1x M.2 2280 B key (PCIe x1) and 1x M.2 2242 M key (PCIe x1, SATA shared with NVMe)
Environment
Operating Temperature
With extended temperature peripherals: -30 ~ 60 °C (-22 ~ 140 °F) with 0.7m/s air flow
Environment
Storage Temperature
- 40 ~ 85° C (-40 ~185° F)
Power
Input Voltage
12 VDC power input
Power
Power Adaptor
Input: 100-240Vac, Output 12Vdc, 60W
Ethernet
LAN1
10/100/1000/2500 Mbps Intel i226 GbE, support Wake On LAN
Audio
Main System
Realtek ALC888S, High Definition Audio, Line-out, Mic-in
I/O Interface
Serial Port
4 x RS-232/422/485
I/O Interface
USB Interface
2 x USB 3.2, 2 x USB 2.0
Environment
Relative Humidity
95% @ 40° C (non-condensing)
Environment
Shock During Operation
30G, IEC60068-2-27, half sine, 11m duration
Environment
Vibration During Operation
3 Grms, IEC60068-2-64, random, 5~500 Hz, 1hr/axis
Certification
EMC
CE, FCC, CCC, BSMI
Certification
Safety Certifications
CB, UL, CCC, BSMI
Expansion
M.2
3x, including 1x M.2 2230E key, 1x M.2 2242 M key and 1x M.2 2280 B key with nano SIM holder
Power Consumption
Max.
19.72W
Power Consumption
Typical
10.05W
Mechanical
Construction
Aluminum housing
Mechanical
Dimensions
133 x 46.4 x 94.2mm (5.24" x 1.83" x 3.71")
Mechanical
Mounting
DIN-rail/Wall Mount
Mechanical
Weight
0.7 kg (1.55 lb)
Others
TPM
TPM 2.0 built in
Others
Watchdog timer
255 levels timer interval, setup by software
Software Support
Linux
Ubuntu 22.04
Software Support
Microsoft Windows
Windows 10/11 IoT Enterprise LTSC
