| Description |
UNO-2271G, Intel® Atom™ E3825 Dual-core Pocket-Size Edge Gateway, Ignition Edge(Linux) |
UNO-2372G, Intel® Atom™ E3845 Quad-core Small Edge Gateway, Ignition Edge(Linux) |
UNO-2484G, Intel® Core™ i3/i5/i7 Modular Edge Platform, Ignition Edge(Linux/Windows) |
Class I, Division 2 Certified, UNO-1372GH, Intel® Atom™ Quad-core E3845 Din-rail Edge Gateway, Ignition Edge(Linux) |
Processor/
Memory
|
Intel Atom E3825 Dual Core 1.33Ghz with 4GB Memory |
Intel® Atom Quad Core E3845 1.91GHz with 4GB Memory |
7th Gen Intel Core i7-7600U, 2.8GHz
i5-7300U, 2.6GHz
i3-7100U, 2.4GHz |
Intel® Atom E3845 1.91GHz processor with 4GB memory |
OS
Supported
|
Ubuntu 18.04 |
WIN10 LTSC
Ubuntu 18.04
|
WIN10 LTSC
Ubuntu 18.04 |
WIN10 LTSC
Ubuntu 18.04 |
| Storage |
Onboard 32GB eMMC |
1x 2.5” SATA HDD/SSD, |
4 x GbE, 4 x USB 3.0, 1 x HDMI, 1 x DP, 4 x RS232/422/485 |
3 x GbE, 3 x USB, 2 x COM, 1 x VGA, 1 x HDMI,
4 x DI, 4 x DO |
| Interface |
2 x GbE, 1 x USB 3.0, 1 x HDMI, optional 2 x RS-232/422/485 or 3 x USB2.0 |
2 x GbE, 4 x USB, 4 x RS-232/422/485, 1 x HDMI, 1 x DP |
4 x GbE, 4 x USB 3.0, 1 x HDMI, 1 x DP, 4 x RS232/422/485 |
3 x GbE, 3 x USB, 2 x COM, 1 x VGA, 1 x HDMI,
4 x DI, 4 x DO |
Wireless connectivity
(Optional) |
WIFI/BT or LTE |
WIFI/BT, LTE |
WIFI/BT, LTE |
WIFI/BT, LTE |
| Ignition Edge Options |
Ignition Edge IIoT
Ignition Edge Panel Ignition Edge Compute |
Ignition Edge IIoT
Ignition Edge Panel Ignition Edge Compute |
Ignition Edge IIoT
Ignition Edge Panel Ignition Edge Compute |
Ignition Edge IIoT
Ignition Edge Panel Ignition Edge Compute |
| Operating Temp |
0 ~ 50°C (32 ~ 122°F) |
-20 ~ 60°C (-4 ~ 140°F) |
-20 ~ 60°C (-4 ~ 140°F) |
- 20 ~ 60°C (-4 ~ 140°F) |
| Dimensions |
100 x 70 x 30 mm (3.9" x 2.8" x 1.2"), |
Single stack: 150 x 105 x 35mm Double Stack: 150 x 105 x 65mm |
200 x 140 x 70 (7.8" x 5.6" x 2.8") |
85 x 139 x 152 mm (3.3" x 5.5" x 6.0") |
| |
