Processor/
System |
Intel Atom® E3940 QC SoC |
Intel Core i5-4300U 1.9GHz |
Intel Atom® E3825/ E3845 QC SoC |
Intel Atom® E3845 QC SoC |
Intel Atom® processor E3900 series |
Intel Atom® processor E3900 series |
Intel Celeron J1900 2.0GHz |
Intel Celeron N3060 1.6GHz |
NXP ARM® Cortex® A9 i.MX6 Dual Lite processor |
Rockchip ARM® Cortex® A17 RK3288 Quad cores processor |
Intel® Atom® E3940 Quad Core SoC |
Intel® Celeron® G3900 Processor |
Intel Atom® processor E3900 series |
| Memory |
DDR3L Max. capacity 8GB |
8GB DDR3 Memory Built-In |
DDR3L Max. capacity 8GB |
DDR3L Max. capacity 8GB |
DDR3L 1866 Max 8GB |
8 GB/8 GB per SO-DIMM |
4GB DDR3 Memory Built-In
Supports up to 8GB |
4GB DDR3 Memory Built-In
Supports up to 8GB |
Onboard 1GB DDR3 memory |
Onboard 2GB DDR3 memory |
DDR3L 1866 Max 8GB |
32GB (up to 16GB per SO-DIMM) |
DDR3L 1866 Max 8GB |
| Display |
HDMI1 + HDMI2 |
VGA, HDMI, LVDS (optional) |
VGA + HDMI |
VGA + HDMI |
HDMI+DP1.2 |
VGA + HDMI+DP1.2 |
VGA |
VGA, HDMI |
HDMI |
HDMI+VGA |
HDMI+VGA |
Intel® HD Graphics |
HDMI+DP1.2 |
| Expansion |
1 x Full-size mPCIe w/ SIM holder
1 x M.2 2230 E key for WIFI |
1x Full-size Mini-PCIe
1x Half-size Mini-PCIe |
1 x Full-size Mini PCIe
1 x Full-size Mini PCIe w/SIM holder
2 x Full-size Mini PCIe w/SIM holders |
1 x Full-size Mini PCIe
1 x Full-size Mini PCIe
1 x Full-size Mini PCIe (USB) w/Accessible SIM socket |
1 x Full-Size Mini PCIe
1 x M.2 E key for WiFi |
1 x Full-size MiniPCIe
1 x M.2 E key support Wi-Fi module |
1x Full-size Mini-PCIe
1x Half-size Mini-PCIe |
2x Full-size Mini-PCIe |
1 x Half-Size Mini PCIe
1 x Fill-Size Mini PCIe
1 x SD Socket |
1 x Full size mini PCIe
1 x M.2 2230 Key.E
1 x microSD socket |
1 x full size Mini PCIe
1 x M.2 2230 E Key |
1 F/S miniPCIe
1 H/S miniPCIe |
1 x Half-Size Mini PCIe
1 x Full-Size Mini PCI
1 x M.2 E key support Wi-Fi module |
| I/O Ports |
4 x USB 3.0
2 x RS-232/422/485
2 x GbE LAN
1 x 8-bit GPIO (Optional) |
2x USB3.0
2x USB2.0
1x RS-232
2x RS-232/422/485
2x GbE
8 bit GPIO |
3 x USB 2.0
1 x USB 3.0
2x non-isolated RS-232/422/485 with auto flow control
Option, 2ch CANBus 2.0A/B
6 x DI & 2 x DO w/ 3KV isolation Input Voltage |
1 x USB 2.0/3.0 M12
2 x USB 2.0
2 x RS-232/422/485 port with auto flow control
8bit Programable DI/DO |
4 x USB 3.0
1 x RS-232 (Option to MDB)
1 x ccTalk (option to RS-422/485)
Support TPM2.0 (Option)
1 SATA for 2.5" SSD & HDD |
4 x USB 3.0
4 x USB 2.0
5 x RS-232
1 x RS-232/422/485
2 x Audio Jack(Line-Out, Mic-In)
up to 2x Antenna (optional) |
1 x USB3.0
7 x USB2.0
6 x RS-232
2 xGbE |
2x USB3.0
4x USB2.0
2x RS-232
2x RS-232/422/485
2x GbE" |
2 x USB 2.0
1 x RS-232
1 x GbE LAN
1 HDMI with 1080p |
6 x USB 2.0
5 x RS-232
1 x RS-485
1 x GbE LAN
1 HDMI with 4K
1 VGA with 1080p |
2 x USB 3.0
4 x USB 2.0
2 x RS-232
2 x RS-232/422/485
Support TPM2.0 |
4 x USB2.0
1 x RS-232
1 x RS-232/422/485
2 (Line-Out, Mic-In) |
2 USB3.0 port
1 x RS-232
1 x RS-422/485
Support TPM2.0 |
| Wide Temp* |
-30 ~ 70 °C (-22 ~ 158 °F)
with 0.7 m/s air flow |
-20 - 55°C* |
-30 ~ 60° C with 0.7m/s air flow (standard) -40 ~ 70° C with 0.7m/s air flow (by project) |
-40 ~ 70 °C EN50155 TX |
-0 ~ 50 °C (with RF module)
-20~60°C (with RF module) by project |
0 ~ 45 °C (32 ~ 122 °F) |
0 - 50°C (fanless: 0 - 40°C) |
0 - 50°C |
0 ~ 60 °C |
0 ~ 55° C |
- 40 ~ 85 °C |
0 ~ 45 °C |
- 40 ~ 85 °C |
| OS Supported |
Windows 10 Enterprice |
WES7E, Win10 Enterprice |
Win7, WES7, Win10 Enterprice |
Win 10 Ent |
Win 10 Ent |
Yocto 2.1 (Kernel 4.1.15)
Android 6.0.1 |
Debian 9
Android 6.0.1 |
|
|
|
|
|
|
