Media Converters

Most industrial computer systems come with standard RS-232 serial ports. Though widely accepted, RS-232 has limited transmission speed, range and networking capabilities. The RS-422/485 standards overcome these limitations by using differential voltage lines for data and control signals. The RS-422/485 repeater simply amplifies, or boosts, existing RS-422/485 signals to enable them to cover longer distances. It extends the communication distance by 1200m (4,000 ft.) or increases the maximum number of connected nodes by 32.

Part Number	I/O		Power Supply		Operating System	General
Part Number	Transmission Distance	Transmission Speed	Power Connector	Power Input	Operating Temperature	Ethernet Connectors	Mounting	Price
EKI-2741SX-AE	Ethernet: Up to 100 m Fiber: Multi-mode: Up to 500 m	Up to 1000 Mbps	6-pin removable screw terminal	2 x Unregulated 12 ~ 48 VDC	-10 ~ 60°C (14 ~ 140°F)	1 x RJ-45 1 x SC type fiber connector	DIN-rail, Wall	$ 275

EKI-2741LXI-AE	Ethernet: Up to 100 m Single-mode: Up to 10 km	Up to 1000 Mbps	6-pin removable screw terminal	2 x Unregulated 12 ~ 48 VDC	-40 ~ 75°C (-40 ~ 167°F)	1 x RJ-45 1 x SC type fiber connector	DIN-rail, Wall	$ 485

EKI-2741LX-AE	Ethernet: Up to 100 m Single-mode: Up to 10 km	Up to 1000 Mbps	6-pin removable screw terminal	2 x Unregulated 12 ~ 48 VDC	-10 ~ 60°C (14 ~ 140°F)	1 x RJ-45 1 x SC type fiber connector	DIN-rail, Wall	$ 385

EKI-2741F-AE	SFP: Up to 110 km	Up to 1000 Mbps	6-pin removable screw terminal	2 x Unregulated 12 ~ 48 VDC	-10 ~ 60°C (14 ~ 140°F)	1 x SFP type fiber connector	DIN-rail, Wall	$ 195

EKI-2541SI-AE	Ethernet: Up to 100 m Multi-mode Fiber: Up to 2km Fiber: Single-mode: up to 30 km	UP to 100 Mbps	6-pin removable screw terminal	2 x Unregulated 12 ~ 48 VDC	-40 ~ 75°C (-40 ~ 167°F)	1 x RJ-45 1 x SC type fiber connector	DIN-rail, Wall	$ 330

EKI-2541S-AE	Ethernet: Up to 100 m Multi-mode Fiber: Up to 2km Fiber: Single-mode: up to 30 km		6-pin removable screw terminal	2 x Unregulated 12 ~ 48 VDC	-10 ~ 60°C (14 ~ 140°F)	1 x RJ-45 1 x SC type fiber connector	DIN-rail, Wall	$ 240

EKI-2541MI-AE	Ethernet: Up to 100 m Multi-mode Fiber: Up to 2km Fiber: Single-mode: up to 30 km	UP to 100 Mbps	6-pin removable screw terminal	2 x Unregulated 12 ~ 48 VDC	-40 ~ 75°C (-40 ~ 167°F)	1 x RJ-45 1 x SC type fiber connector	DIN-rail, Wall	$ 240

EKI-2541M-AE	Ethernet: Up to 100 m Multi-mode Fiber: Up to 2km Fiber: Single-mode: up to 30 km		6-pin removable screw terminal	2 x Unregulated 12 ~ 48 VDC	-10 ~ 60°C (14 ~ 140°F)	1 x RJ-45 1 x SC type fiber connector	DIN-rail, Wall	$ 175

ADAM-6542/W15-AE	Ethernet : Up to 100 m Fiber: Up to 20 km	UP to 100 Mbps	2-pin removable screw terminal	1 x Unregulated 10 ~ 30 VDC	0 ~ 60°C (32 ~ 140°F) Stack: 0~ 50°C (32 ~ 122°F)	1 x RJ-45 1 x SC type fiber connector	DIN 35 rail, Wall, Stack	$ 395

ADAM-6542/W13-AE	Ethernet : Up to 100 m Fiber: Up to 20 km	UP to 100 Mbps	2-pin removable screw terminal	1 x Unregulated 10 ~ 30 VDC	0 ~ 60°C (32 ~ 140°F) Stack: 0~ 50°C (32 ~ 122°F)	1 x RJ-45 1 x SC type fiber connector	DIN 35 rail, Wall, Stack	$ 360

ADAM-6541-AE	Ethernet: Up to 100 m Fiber:Multi-mode: Up to 2 km Single-mode: Up to 20km	UP to 100 Mbps	2-pin removable screw terminal	1 x Unregulated 10 ~ 30 VDC	0 ~ 60°C (32 ~ 140°F) Stack: 0~ 50°C (32 ~ 122°F)	1 x RJ-45 1 x SC type fiber connector	IP30, ABS+PC with solid mounting kits	$ 165

ADAM-6541/ST-AE	Ethernet: Up to 100 m Fiber:Multi-mode: Up to 2 km Single-mode: Up to 20km	UP to 100 Mbps	2-pin removable screw terminal	1 x Unregulated 10 ~ 30 VDC	0 ~ 60°C (32 ~ 140°F) Stack: 0~ 50°C (32 ~ 122°F)	1 x ST type fiber connector	IP30, ABS+PC with solid mounting kits	$ 165
